SmartGen HGM6110N Generator Controller Single Unit Automation Remote Signal Start/Stop Automatic Start Module with USB Interface Gernerator Part

Features:Display:LCD(132*64)Operation Panel:Silicon RubberLanguage:Chinese & English & OthersDigital Input:5Relay Output:6Analogue Input:3AC System:1P2W/2P3W/3P3W/3P4WAlternator Frequency:50/60HzkW/Amp Detecting & Display:YesProgrammable Interface:USBRTC & Event Log:YesScheduled Start Genset:YesMaintenance:YesDC Supply:DC(8～35)VCase Dimensions(mm):209*166*44Panel Cutout(mm):186*141Operating Temp.:(-25～+70)℃With ETS, idle control, pre-heat control, speed raise/drop control, all of them are relay outputs;Parameter setting: Allow user to modify setting and store them in internal FLASH memory. The parameters cannot be lost even when power off. All of parameters can be set not only from the front panel, but also adjusted through USB interface (or RS485 interface) via PC;Multiple sensors of temperature, pressure and fuel level can be used directly, parameters can be defined by user;Multiple conditions of crank disconnect (speed, oil pressure, frequency) can be selected;With emergency start function;With flywheel teeth numbers automatic identification function;All parameters use digital modulation, instead of analog modulation using conventional potentiometer, having improved reliability and stability;With maintenance function. Types (date or running time) can be selected and actions (warning or alarm shutdown) can be set when maintenance time out;Event log, real-time clock, scheduled start & stop function (can be set as start unit once a day/week/month whether with load or not);Add rubber gasket between shell and controller screen, the waterproof can reach IP65;Controller is fixed by metal fixing clips;Modular design, flame-retardant ABS shell, pluggable terminal, embedded mounting, compact structure and easy installation.

• HGM6100N series automatic controller, integrating digital, intelligent and network techniques, is used for automatic control and monitoring system of single genset. It can carry out functions of automatic start/stop, data measurement, alarm protection and “three remote” (remote control, remote measurement and remote communication).
• The controller uses LCD display, optional language interface including Chinese, English, Spanish, Russian, Portuguese, Turkish, Polish and French with easy and reliable operation.
• HGM6100N series automatic controller uses micro-processing technique which can achieve precision measurement, value adjustment, timing and threshold setting etc.
• All the parameters can be configured from front panel or use USB interface (or RS485 interface) to adjust via PC.
• It can be widely used in all types of automatic control system for its compact structure, simple connections and high reliability.
